바이오가스용 활성탄

Activated carbon is the essential purification material for biogas treatment, delivering proven removal of hydrogen sulfide, siloxanes, and volatile contaminants that damage equipment and block compliance with biomethane grid injection, combined heat and power generation, and vehicle fuel quality standards.

What is Biogas Activated Carbon？

Methane Active Carbon is a specially chosen class of active carbon, which is applied throughout the cycle of cleaning and upgrading of biogas, to eliminate a complicated mix of noxious contaminants which pollute virgin methane at the place of manufacture. Raw biogas – produced by the anaerobic digestion of organic raw materials such as farm refuse, food residues, urban solid garbage, landfill gas, and sewage sludge – is a major energy source, but it also has a substantial amount of hydrogen sulphide (H₂S), siloxanes, halogens (VOCs), ammonia, and water, which need to be eliminated in order to make safe and efficient use of the gas.

If not addressed, these pollutants will have significant operating and business implications. Hydrogen sulphide erodes metal pipes, motors, and heat exchangers at increasing speeds. Siloxanes are deposited as abrasive silica on burning surfaces, resulting in early engine wear and expensive unscheduled maintenance. Halogens and VOCs may be toxic to the catalyst and the EGR system. Taken together, such impurities render crude biogas unfit to comply with the requirements of the Biomethane Network Injection, Cogeneration (CHP), and Vehicle Fuel Certification – so that efficient cleaning is not an option but an operational and commercial necessity.

Active carbon combines high absorption capability, chemical versatility, and the ability to adapt to the process so that no other treatment material can match the whole biogas contamination spectrum.

Key Advantages of Biogas Activated Carbon

The selection of appropriate active carbon levels for biogas treatment will have a direct impact on the results of the gas quality, the lifetime of the installation, and the profit margin of the entire plant. HPC Active Carbon Provides Measurable Benefits in All Key Aspects of Wastewater Treatment:

Highly Effective H₂S Removal: Active carbon - especially an impregnation grade of K- or KMnO - enables highly efficient absorption of H2S even at high entry levels, thereby shielding the downstream motor, turbine, and heat-exchanger from accelerated corrosion.
Reliable Siloxane Capture Across Operating Conditions: The well-developed micro-poro- and mesoscopic architecture of the superior methane carbon classes guarantees efficient absorption of siloxane over a variety of methane compositions, flow rates, and moisture levels – preventing the formation of silica on the combustion surface and the significant extension of engine repair intervals.
Broad Contaminant Coverage in a Single Treatment Stage: At the same time, active carbon deals with H₂S, siloxanes, VOCs, halogens, and remaining water in one fixed bed system, which makes it simpler to process methane and to decrease the need for separate cleaning units.
Compatible with Impregnation for Enhanced Performance:Chemical enhancement of standard active carbon can be performed through potassium permanganate, potassium iodide, or amine impregnation to target specific contaminants — particularly H₂S and mercury — at removal efficiencies that physical adsorption alone cannot achieve, providing a tailored solution for challenging biogas compositions.
Supports Biomethane Certification and Regulatory Compliance: Active Carbon Cleaning System is a recognised and demonstrated way to meet the requirements of European EN16723, CHP Generator Producer Specification, and Vehicle Fuel Quality Rules in World Markets.

업계의 과제

High H₂S Concentrations Overwhelm Standard Carbon

Biogas from certain raw materials — especially manure and food waste digesters — can contain H₂S at a concentration of more than a few thousand ppm, quickly filling the unimpregnated activated carbon beds with high cost.

Siloxane Removal Efficiency Declines with Moisture

Increased moisture in crude methane is competitive with silicone molecules for active carbon adsorption sites, decreasing the efficiency of silicone removal and requiring upstream air drying prior to the carbon phase to keep an acceptable cleaning performance.

Short Carbon Bed Service Life Increases Operational Costs

Combined with a large pollutant load and a complicated gas matrix in biogas applications, it speeds up CO 2 saturation, reduces the substitution time, and increases the amount of continuing material and labour costs on the operational budget of the plant.

제품 개요

Specific Use Scenarios — Biogas Activated Carbon

Hydrogen Sulfide (H₂S) Removal

H₂S is one of the most destructive and ubiquitous pollutants in natural gas, corrosive metallic infrastructure, toxic catalysts, and generating toxic SO2 emissions. Active carbon — especially those dipped in potassium iodide or potassium permanganate — is highly efficient in absorbing and chemical oxidation of H₂S over a broad range of input concentrations, thereby protecting the downstream motor, the turbine, the boiler, and the gas upgrading membrane from the acceleration of corrosion and the extension of the service time.

Siloxane Removal

Siloxanes — organic-silicone compounds derived from personal care products, cleaning agents, and industrial chemicals in waste raw materials — are one of the most difficult techniques to control. Upon combustion, the siloxanes are transformed into abrasive silica (SiO2) deposits that build up on the pistons, the head, and the heat exchanger surfaces, resulting in serious mechanical wear and unscheduled maintenance stops. Active carbon with well-developed micro-holes can efficiently adsorb all the D and L classes of silicone compounds, thus protecting CHP motors and gas turbines against the harm caused by silicon dioxide.

VOC and Halogenated Compound Removal

Methane produced from MSW and IDD often has a complicated mix of VOCs and halogens – including chlorine and fluorine – which can destroy the incineration plant, poison the catalytic converter and cause poisonous emissions if not treated. Active carbon has wide absorption spectrum and large surface area, which can effectively trap VOC and halogens in one fixed bed phase, so that the process can be simplified and the system complex can be decreased.

Odor Control in Biogas Handling Facilities

Anaerobic digestion facilities, landfill gas collecting stations, and biogas upgrading plants produce significant environmental odour from fugitive H₂S, mercaptans, and other malodorous sulphur compounds that leak during the gas handling, storage, and treatment operations. Active Carbon Odour Control Systems – installed in the ventilating exhaust flow, the construction air-treatment plant, and the treatment outlet scrubber – collect the odour from the premises prior to their arrival at the site’s borders, thereby facilitating compliance by the regulator with the smell emission limit and the maintenance of an acceptable environment for the staff of the facility and the surrounding communities.

Biogas Pre-Treatment Before Membrane Upgrading

The PSA (PSA) and the membrane separating system for the upgrading of the bio-diesel engine are very sensitive to micropollutants – especially H₂S, siloxanes and VOCs – which may cause irreversible degradation of the separating membrane or decrease its selectivity and yield with time. Active Carbon Guard Beds located upstream from the Membrane and PSA Improvement Unit serve as Polishing Pretreatment Phase, Removal of Remaining Pollutants to Levels Lower than Acceptable Limits for Upgrading Techniques and Safeguarding the Capital Invested Embodied in the Downstream Separating System.

Biogas Pre-Treatment Before Membrane Upgrading

Landfill gas is one of the most complicated and varied types of biogas pollutants, which include not only H₂S and siloxanes, but also a wide variety of nonmethane organic compounds (NMOCs), halocarbons and mercury vapour due to the heterogeneous constituents of underground urban solid waste. Active Carbon – including special dipping grades for Hg and Halon – has been introduced into the LFG treatment system to deal with this multiple contamination problem, allowing the site operator to improve the primary LFG into pipeline quality biomethane or to produce electricity on site under the regulation’s emission limits.

Our Biogas Activated Carbon Advantages

Multi-Contaminant Removal in a Single Treatment Stage

Active carbon simultaneously absorbs H₂S, siloxanes, VOCs and halogens in a single solid bed system, thus avoiding the necessity of a plurality of separate cleaning units, and substantially reducing the complexity, size, and cost of the biogas processing train.

Impregnation-Enhanced Performance for Demanding Biogas Compositions

Both standard and chemical immersion active carbon classes — including KSI and KMP variants — deliver tailored removal efficiency for high-concentration H₂S and trace contaminants, ensuring consistent gas quality output even as feedstock composition and inlet contaminant levels

Proven Pathway to Biomethane Compliance and CHP Protection

Active Carbon Cleaning System is an internationally accepted solution to meet the Biomethane Grid Injection Standard and CHP Engine Producer Gas Quality Norms.

모든 활성탄 카테고리 보기

A correct activated carbon class distinguishes from a high level of reliability in biomethane and expensive carbon replacement. We offer a wide variety of active carbon products including granular, column, and chemical impregnation grades that are particularly suitable for the removal of H₂S, the trapping of silicone and the VOC absorption of methane. Look through our complete active carbon catalogue for your feed mix, flow demand, and gas quality goals.

모든 산업용 솔루션 보기

Biogas purification is one application within a much broader landscape of industrial challenges that advanced chemical materials are engineered to solve. Regardless of whether you operate from renewables, water-treating, air-cleaning, food-handling, or environmental remediation, we have a comprehensive portfolio of products that use active carbon, aluminum oxide, titanium dioxide, and other high performance materials. Examine our industrial solutions to identify appropriate solutions for your business and business needs.
